Epson EB-1400Wi Projector

Discontinued

Manufactured
2012 to 2015

Alternative Projectors

Enquire

Overview

Specifications

Projector Lamp

The ultimate meeting solution in one simple device

A must for every meeting room, the interactive Epson EB-1400Wi is the complete solution for all meeting scenarios including instant meetings, boardroom presentations, brainstorming and training sessions.

With whiteboard function, dual pen interactivity (2 pens included), control pad operation and brightness of up to 2,600 lumens Light Output and 2,600 lumens Colour Light Output, the EB-1400Wi is perfect for any meeting room.

Highlights

Whiteboard Function – Perfect alternative to copy boards, conventional whiteboards and old fashioned flip charts, this easy-to-use function facilitates “instant meetings” without the need for a PC! After the meeting, you can save, print or email the meeting notes.

Save – Load and save image files on USB or network drive.

Print – Print your meeting notes wirelessly (peer to peer) or to the network printer.

Email – Instantly share your meeting notes via email – to an individual or group address.

Capture – Capture a screenshot from other sources (eg PC, DVD, iPad etc) and annotate over it on the whiteboard. From there you can save, print or email the annotated version.

Split Screen Function – Allows images from 2 input sources to be projected simultaneously.

Control Pad for Easy Operation – Neatly designed and easy to install control pad for efficient and intuitive operation. All buttons on the control pad can also be found on the remote control.

Remote Interactive Collaboration – Collaborate from multiple remote locations (up to 4)*

Wireless Projection and Interactivity – Projection and interactive function without the wires (using peer to peer wireless and Epson’s EasyMP Network Projection software version 2.81)

Dual Pen Interactivity – With simultaneous dual pen functionality, you and a colleague can annotate at the same time.

No Driver Installation Required – Installation has never been easier (Driver install is required for Mac)

Advanced Networking Capability – Enables users to monitor, control and present from a remote location

Broad Connectivity Including HDMI – HDMI, DisplayPort, USB display, PC Free slideshows, network and wireless connectivity

10W Built-in Speaker – Built in audio with the power to fill the meeting room

Specifications:


Resolution

WXGA (1280 x 800)

Aspect Ratio

16:10 native

Selectable Aspect

4:3, 16:9

Brightness

2600 lm (3500 hrs)

Eco Brightness

1800 lm (5000 hrs)

Uniformity

Contrast Ratio

3000:1 On/Off

Iris

Dynamic

Colours

16.7 Million

Refresh Rate

24-85 Hz

Latency

Progressive

Yes

Shaping

Stackable

Keystone

Digital

Horizontal

5°

Vertical

5°

System

Lamp Code

ELPLP71 / V13H010L71

Lamp Type

Lamp

Panel

0.59" LCD(3) with MLA

Organic Panels

Organic

Segments

Speed

Lens

Options

Focus

Manual

Zoom

Fixed
Digital (1.35x)

Offset

Screen Size

60 - 100"

Throw Distance

35 - 60 m

Throw Ratio

0.27 - 0:1

Lens Shift

Horizontal

Vertical

Physical

Weight

5.9 kg

Dimensions

36.7 x 37.5 x 15.5 cm

Operation

Positioning

Table, Ceiling, Front, Rear,

Rotation

360°(up, down)

Cooling System

Air

Fan Noise

35 dB

Eco Fan

28 dB

Air Filter

Yes

Filter Code

ELPAF40

Security

Slot

Power

On/Off

Mains

278 W

Eco

215 W

Standby

0.3 W

Battery Capacity

Battery Life Normal

Battery Life Eco

Warranty

Projector

2 year

Lamp

90 Days, 500hrs

Production

Country of Origin

Philippines

Launch Date

October 2012

Discontinuation Date

January 2015

Connections:

Inputs

BNC

Component Video

via adaptor

Composite

RCA

Digital

HDMI

Display Port

Yes

Video LAN

VGA

VGA(x2)

S-Video

USB

A(memory, wifi)(x2)
B(display)

Mini Jack

3.5mm(x3)

RCA Audio

Microphone

Disc Drive

Network

Serial

RS232c

LAN

LAN (RJ45)

WiFi

WiFi (b/g/n)

Bluetooth

Memory

Internal

SD Card

USB

Memory Stick

Outputs

BNC

Component Video

Composite

Digital

Display Port

Video LAN

VGA

S-Video

USB

Mini Jack

3.5mm

RCA Audio

Speakers

10W Mono

Trigger

Compatibility

DICOM

Simulation

Mac

Yes

1080p, 720p, 576p, 480p

Phone

iOS

Software

Crestron

Media Server

Image Files

bmp, jpeg, png, tif

Video Files

Audio Files

Office Files

pdf

Brochure

Manual

Do You Need a Spare / Backup Projector lamp?

The replacement projector lamp for the Epson EB-1400Wi is: ELPLP71 / V13H010L71

ELPLP71 / V13H010L71 Lamp Specifications.

2600 Lumens, 215W ( W Eco), Lamp Lamp, Life expectancy 3500 hours (5000 Eco)

Options	Qty	Warranty	Price
Original Epson Lamp	1	90 days *	$227.00 inc
Origen Lamp	1	180 days *	$210.00 inc
